| Physical Parameters | |
| ACU Size | 400X300X50mm（Without Bracket） |
| Cover Materials | Aluminum alloy |
| Operating temp.range | -25~60 ℃ |
| Installation method | Rack mount |
| ACU Size | 400X300X50mm（Without bracket） |
| Supporting Functions | |
| Supports access to satellite broadband networks | |
| Supports button control and GUI display | |
| Supports multi-link network load balancing | |
| Supports remote upgrades | |
| Supports front-end user network billing | |
| Supports multicast access function | |
| Hardware Parameters | |
| Processor model | RK3568 |
| EMMC(flash memory) | 32GByte |
| DDR(RAM) | 2GByte |
| LCD (Display) | 3.71 inch |
| Front camera pixels | 2 Million (2 M) |
| Peripheral interface | Satellite antenna interface |
| Power supply interface (DC) | |
| WAN port | |
| Power button | |
| Button | |
| Voice interface | |
| 100Mbps Ethernet port * 4 | |
| Debug serial port | |
